Fluid Pneumatic Seals – Piston Seals

Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK01P
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK01PE
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK01R
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement160 bar0,5 m/s
Piston Seal, TK01RE
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement160 bar0,5 m/s
Piston Seal, TK02P
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement700 bar0,7 m/s
Piston Seal, TK02PD
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement700 bar0,7 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK02R
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement250 bar0,5 m/s
Piston Seal, TK02RD
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement250 bar0,5 m/s
Piston Seal, TK03F
Food-, Pharmaceutical- and
Chemical industry, single-acting
Linear movementLinear movementConditional static movementConditional static movement400 bar1 m/s
Piston Seal, TK03FS
Food-, Pharmaceutical- and
Chemical industry, single-acting
Linear movementLinear movementConditional static movementConditional static movement400 bar1 m/s
Piston Seal, TK03P
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK04P
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement700 bar0,7 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK04PD
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement700 bar0,7 m/s
Piston Seal, TK05P
Pneumatic, single acting
Linear movementLinear movement25 bar2 m/s
Piston Seal, TK05R
Pneumatic, single acting
Linear movementLinear movement25 bar1 m/s
Piston Seal, TK06P
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK06R
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement160 bar0,5 m/s
Piston Seal, TK07F
Food-, Pharmaceutical- and
Chemical industry, single-acting
Linear movementLinear movementConditional static movementConditional static movement400 bar1 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK07P
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK08D/F
Hydraulic, double acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar10 m/s
Piston Seal, TK08D/X
Hydraulic, double acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar5 m/s
Piston Seal, TK08DS/F
Hydraulic, double acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar10 m/s
Piston Seal, TK08DS/X
Hydraulic, double acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar5 m/s
Piston Seal, TK08E/F
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar10 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK08E/X
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar5 m/s
Piston Seal, TK08ES/F
Hydraulic, single acting
Linear movementLinear movement600 bar10 m/s
Piston Seal, TK08ES/X
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movement600 bar5 m/s
Piston Seal, TK08P
Hydraulic, double acting
Linear movementLinear movement250 bar1,4 m/s
Piston Seal, TK09D
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK09F
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement400 bar1,5 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK09H
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement1500 bar0,3 m/s
Piston Seal, TK09N
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK10M
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional static movementConditional static movement500 bar0,7 m/s
Piston Seal, TK10T
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional static movementConditional static movement500 bar0,7 m/s
Piston Seal, TK13T
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement600 bar0,7 m/s
Piston Seal, TK15P
Hydraulic, double acting
Linear movementLinear movementStatic movementStatic movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movement400 bar
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK16A
Hydraulic / pneumatic, single acting
Linear movementLinear movementConditional rotating movement (one direction)Conditional rotating movement (one direction)Conditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement160 bar5 m/s
Piston Seal, TK16B
Hydraulic / pneumatic, single acting
Linear movementLinear movementConditional rotating movement (one direction)Conditional rotating movement (one direction)Conditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement160 bar5 m/s
Piston Seal, TK17H
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement250 bar0,7 m/s
Piston Seal, TK17P
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement250 bar0,7 m/s
Piston Seal, TK17R
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement250 bar0,5 m/s
Piston Seal, TK19F
Food-, Pharmaceutical and-
Chemical industry, single-acting
Linear movementLinear movementConditional rotating movement (one direction)Conditional rotating movement (one direction)Conditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement400 bar15 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK20E
Hydraulic, single acting
Linear movementLinear movementStatic movementStatic movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movement700 bar0,5 m/s
Piston Seal, TK20R
Hydraulic, double acting
Linear movementLinear movementStatic movementStatic movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movement700 bar0,5 m/s
Piston Seal, TK21P
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK22P
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK22R
Hydraulic, single acting
Linear movementLinear movementConditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movementConditional static movementConditional static movement160 bar0,5 m/s
Piston Seal, TK23D
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK23F
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement400 bar1,5 m/s
Piston Seal, TK23H
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement1500 bar0,4 m/s
Piston Seal, TK23N
Hydraulic, double acting
Linear movementLinear movementConditional static movementConditional static movement400 bar0,7 m/s
Piston Seal, TK24P
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement500 bar0,7 m/s
Piston Seal, TK32P
Hydraulic, single acting
Linear movementLinear movementConditional static movementConditional static movement500 bar0,7 m/s
Piston Seal, TK35P
Hydraulic, double acting
Linear movementLinear movementStatic movementStatic movementConditional rotating movement (one direction)Conditional rotating movement (one direction)Conditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movement400 bar0,5 m/s
Product
standard application
Direction
mouse over symbol
Pressure
maximum
Sliding Speed.
maximum
Piston Seal, TK37P
Hydraulic, double acting
Linear movementLinear movementStatic movementStatic movementConditional rotating movement (one direction)Conditional rotating movement (one direction)Conditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movement50 bar
Piston Seal, TK37R
Hydraulic, double acting
Linear movementLinear movementStatic movementStatic movementConditional rotating movement (one direction)Conditional rotating movement (one direction)Conditional oscillating movementConditional oscillating movementConditional screwing movementConditional screwing movement50 bar
Piston Seal, TK50
Hydraulic, double acting
Linear movementLinear movementStatic movementStatic movement360 bar1 m/s
